FEATURES

• High-performance air reversing valve, safe, reliable and stable.

• The pump station is made of aluminum-titanium alloy, light in weight and easy to carry;

• For driving two hydraulic wrenches at the same time (four-wrenches configuration is available at to customer requirements);

• The pressure can be adjusted continuously from 4-70MPa

• The pressure of the air source needs to meet the requirements of 4-8bar

• System pressure release button can release pressure when the hydraulic pump stops working;

• Steel scripture structure protection frame, which can protect the fuselage and facilitate transportation.

• Seismic pressure gauge, with high resolution, high repeatability, impact resistance and low failure rate.

• Equipped with air source filter, pneumatic pressure reducing valve, oil mist device can provide clean and lubricated compressed air.

• The design of cartridge relief valve has stable performance, low noise, convenient maintenance and low maintenance cost.

• Aluminum explosion-proof handle, solid and reliable.

SPECIFICATIONS
